Aurora - LEDHOME flexible wall washer rope is developed and improved from traditional aluminum heavy wall washer. New innovation on architecture lighting solution for facade lighting and landscape lighting, more economic cost and easiest installation way. Polyrethane encapsulated led flexible wall washer, it features as slender bendable strip and smaller size, then realize many irretular installation in coves, domes and so on. We can choose different beam angle 15°/ 30°/45°/60°/20*45°/ 15*60° asymetrical for different lighting design..png) .png) | |||
| | |||
| Luminaire | Size | ||
| Item Reference: | FW35OP-White |  | |
| Product: | Flexible LED Wall washer | ||
| Material: | 100% TPU | ||
| Light Emitting: | Topview | ||
| Beam Angle: | 110° x 70° (Asymmetric) | ||
| Max. Weight: | 0.5 kg/meter | ||
| Color: | 2700K/3000K/4000K/6500K | ||
| IP Rate: | IP67 | ||
| Warranty: | 5years | ||
| Light Source | Optics | ||
| Light source: | FW35OP-White | Light emission: | 110° x 70° (Asymmetric) |
| Brand: | Epistar chip | Light controller: | PMW/Triac/0-10Vdim/Dali |
| LED Qty: | 35LED/m | Color temperature: | 2700K/3000K/4000K/6500K |
| Power:(per meter) | 74W | UGR: | >19 |
| Lumen output (2700K): | 4945LM/M | CRI: | 80 |
| Efficency: | 66.8lm/w | Lumen Maintenance: | 70,000 Hours L70 @ 25°C |
| Max length: | 16.4ft (5m) | 90,000 Hours L50 @ 25°C | |
| Power Feed: | two end feed | 50,000 Hours L70 @ 50°C | |
| Deviation(SDCM) : | 3step | 70,000 Hours L50 @ 50°C | |
| Electrical | Temperature Range | ||
| Input Voltage(V): | DC24V | Installation: | -40°F to 134°F (-40°C to 55°C) |
| Control gear type: | Contant voltage DC24V driver | Operating: | -25°F to 131°F (-25°C to 55°C) |
| Ref: | Meanwell | Humidity: | 0-95% non condensing |
| Emergency: | / | ||
| Performance | Instalaltion | ||
| Fire Proof: | V1 | Environment: | IP67 |
| Tensile Force: | Type: | Surface mount | |
| Inpact test: | Accessory: | Clip, alu channel, adjustable bracket | |
| Silicon Purity: | TPU | Cut length: | 200mm |
| SHORE: | Minimum Bend Diameter | 3.94in (100mm) (Vertical Bending) | |
| Conductivity Index: | 0.3-0.5 | Dimension(mm): | 20×5mm |
| Certifacte: | CE/ RoHs | Note: | |
| Application | |||
Extensively applied in Backlighting for signage letters, concealed lighting and advertisement sign lighting. | |||
| Architectural decorative lighting,Archway, canopy and bridge edge lighting, Security lighting and Emergency | |||
